Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince

Certification
China ZheJiang Tonghui Mining Crusher Machinery Co., Ltd. certification
China ZheJiang Tonghui Mining Crusher Machinery Co., Ltd. certification
I'm Online Chat Now

Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince

Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince
Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince

Large Image :  Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince

Product Details:
Place of Origin: CHINA
Brand Name: TONGHUI
Model Number: HCC66
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: Resonable
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 5 units/month

Quarry 250Tph Stone Hydraulic Cone Crusher 50000kgs Easy Maintaince

Description
Type: Cone Crusher Motor Type: AC Motor
Capacity(t/h): 330-725 Condition: New
Warranty: 1 Year Application: Mining,construction,Quarry,etc
After-sales Service Provided: Online Support Weight: 50000kgs
Spare Parts Supply: Will Supply Any Time Pre Sales Service::: The Whole Time
High Light:

250Tph Stone Hydraulic Cone Crusher

,

Quarry 250Tph stone cone crusher

,

Hydraulic Cone Crusher 50000 kgs

250 Tph Quarry Stone Hydraulic Cone Crusher Machine



Features:



1. Higher capacity and less wear costs.



2. Wide range of application suitability.



3. Easy to maintain, reduce the downtime and maintenance costs.



4. Stable running performance and easy operation.



5. Stable bevel wheel transmission device



6. Balanced run out rotation ensures capacity.



7. Proper operation, continuously load until the machine shut down scheduled.



Working principle

When cone crusher begins to work, the electric motor drives the eccentric sleeve through the spring coupling, drive shaft and a pair of angle gear, so that the crushing wall of cone crusher gets close to and then gets away from the surface of the rolling mortar wall fixed on the adjusting sleeve, and the ores inside the crushing chamber will be constantly impacted, squeezed and bent to be crushed.


Model:

Model

Max. Feed Size

Discharge Size

Power

Weight

Capacity

HCC45 180mm 13~38mm 110~132kW 15500kg 115~260t/h
HCF45 130mm 10~25mm 110~132kW 15500kg 100~175t/h
HCS45 90mm 10~19mm 110~132kW 15500kg 80~140t/h
HCSS45 60mm 10~19mm 110~132kW 15500kg 74~130t/h
HCC54 215mm 19~51mm 180~220kW 26300kg 200~420t/h
HCF54 160mm 16~25mm 180~220kW 26300kg 155~220t/h
HCS54 115mm 13~22mm 180~220kW 26300kg 150~230t/h
HCSS54 80mm 10~19mm 180~220kW 26300kg 122~200t/h
HCC66 260mm 22~63mm 250~300kW 50000kg 330~725t/h
HCF66 200mm 16~25mm 250~300kW 50000kg 230~330t/h
HCS66 140mm 10~19mm 250~300kW 50000kg 185~340t/h
HCSS66 95mm 10~19mm 250~300kW 50000kg 180~335t/h



1. Are you manufacture or trading company?

We are factory, established in 1968.

2. How long is your delivery time?

7-10 days for the stock, 15-30 days for the mass production.

3. What is your payment method?

30% prepayment by T/T , after the seller finish the production process and buyer verify the machine , 70% balance should paid
before delivery, L/C is also acceptable .

4. How long is the warranty? Does your company supply the spare parts?

One year. Spare parts for you at lowest cost.

5. If I need the complete crushing plant can you help us to build it?

Yes, we can help you set up a complete production line and give you related professional advice. We had already build many mining projects in China & Overseas





Our Services:

Service is one of the most important parts in the whole business. We are always devoted to meeting customer’s need. We insist on providing customers with one-stop service, from model choosing, installation and test run, personnel training, technical support to maintenance.



Before service: Before the contract is signed, we will act as a good adviser and assistant to help customers choose the most suitable equipment and production line, all for the capacity increasing and cost reducing. We design and produce machines according to the actual requirements of customers.



During and after service: After the contract is signed, (1)we will send our most experienced technicians to make an inspection of the working site, (2)our technicians will help customers make a decision on site planning and designing, (3)technology department will offer a installation foundation drawing, (4)finally, technicians will assist customer in the construction. When all the equipment has been delivered to the site, our company will send staff to assist customer in installation and run test. Our company will also provide customer with free training to help customer master the use and simple maintenance of the machines. Once the machine is out of order at work, our company will set up a clear solution during 24 hours after customer’s phone call. Recover the production first, and then ascertain where responsibility lies.
